|Place of Origin:||Jiaxing ,Zhejiang ,China (Mainland)|
|Certification:||CE / ROHS|
|Minimum Order Quantity:||1 Unit|
|Packaging Details:||1unit in 1 Carton / 10 units in 1 Wooden Case|
|Delivery Time:||7 - 10 Days|
|Payment Terms:||T/T, Western Union,Paypal|
|Supply Ability:||100Units/ Per Month|
|Tube Chip Color:||Red||Digit Height:||12'' 300mm|
|Format:||88 : 88 : 88||Sign Size Mm:||370*1500*100|
|Controller:||IR Remote / PVC Buttons Box / Windows Software||Display Function:||Time|
|Cabinet:||Aluminium Frame / Iron Cabinet||Usage:||Outdoor|
electronic countdown timer,
large display digital countdown timer
Super Brightness in Yellow Color LED Countdown Timer Clock for High - Speed Railway Station
|Format :||88 : 88 : 88||Color :||Red|
|Display Size :||370mm x 1500mm||Thickness :||100mm|
|Digit Size :||12'' 300MM||Housing :||Iron Cabinet|
|Communication1 :||IR Remote||Communication Distance :||IR = 10M|
|Communication2 :||Wire||Communication Distance :||RS232 = 50M|
|Communication3 :||Wireless||Communication Distance :||RF433 =1000M|
|Output Voltage :||5V||Volatge Input :||110V ~ 240V AC|
|Brightness :||5000cd / M2||Working Temp :||-30℃ ~ +65℃|
|Viewing Angle :||> 100°||Working Humidity :||5% - 90% RH|
|Life Span :||100,000 Hours||Waterproof :||IP65|
1) Use of the environment: Outdoor and Indoor
2) Brightness: High Level Brightness
3) Height of Number Option : 6'' / 8'' / 10'' / 12'' / 16'' / 20'' / 24'' / 30'' ect.
4) Number Color Option : Red / Green / Amber / Blue / White
5) Frame Color : Black Color (Any other kind is Option)
Overall Structure :
1) Display Sign Include : Numbers ,Controller , Cabinet / Frame ,Power Supply
2) Frame : Iron / Steel
3) Faceplate : Display window cover glass board and UV Protection
4) Drainage Outlet at the bottom of the Frame
5) Fans install inside of scoreboard
Technical Norms :
1) Power Supply : 110V ~ 240V
2) Operation Circumstance: -30℃ ~ 65℃ ,5% ~ 90% relative humidity
Operation Type :
1) Controller Type : IR Remote / PVC Buttons Controller Box / Windows Software
2) Communication Type : IR / Hard - wire / Wireless Type
3) Operation Distance : 10m ~ 1200m.
4) Operation Power : Remote with Battery / Controller Box with 110v ~ 240v Power
Life Time of Leds : 100000 Hours
Installation : Hanging / Mounting / Tripod / With wheels / Custoized Design
Delivery Time : 7days ~ 12days
Warranty : 2 Years
Package Dimension : 440mm x 1570mm x 170mm
|Model||Timer Size||Package Dimension|
|8'' 200mm||300mm x 1000mm x 100mm||370mm x 1070mm x 170mm|
|10'' 254mm||350mm x 1200mm x 100mm||420mm x 1270mm x 170mm|
|12'' 300mm||370mm x 1500mm x 100mm||440mm x 1570mm x 170mm|
|16'' 400mm||610mm x 1950mm x 100mm||680mm x 2020mm x 170mm|
|20'' 500mm||700mm x 2200mm x 100mm||770mm x 2270mm x 170mm|
|24'' 600mm||770mm x 2570mm x 100mm||840mm x 2640mm x 170mm|
|30'' 750mm||920mm x 3140mm x 100mm||990mm x 3210mm x 170mm|
1.Display : Hours : Minutes : Seconds (Support 12/24 Hour)
2.Count up : Count from zero to 99 hours 59 minutes 59 seconds
3.Countdown : Count from 99 hours 59 minutes 59 seconds to zero
4.Stopwatch : minutes, seconds and 1/100 of seconds format,zero up to 99:59:99
5.Interval timer: interval repeating countdown/ count up timer, max 99 rounds
* Install GPS inside as Clock ,then it can search time and Display AUTO.
* Timer can work by Battery .
* Colon between the digits can be dark and the timer can be used to display Sports / Game Scores.
* Extra Function to display Temperature.
Q1. What is your payment ?
A : We accept T/T , Wester Union , Paypal.
Q2. When can you arrange the shipment after i have placed an order ?
A : Usually about 10days after receiving Payment.
Q3. Can you accept customized ?
Q4. Is it OK to print my logo on the product?
A : Yes. Please inform us formally before our production and confirm
1. Where do you load the goods?
We offer shipment by sea or by air as requested by the buyer. The sea port we are used : Shanghai Sea port The airport we are used : Shanghai Airport
2. What is the lead time ?
Usually, the lead time is 7-10 days. 3. Which logistics company do you cooperate with? Our company cooperates with COSCO, APL, CMA, CSAV, K-LINE, MSC and etc. For courier, it’s up to buyer’s option. We will give suggestion according to the time table of the steamers and their services.
Jiaxing Linger Electronic Technology Co., Ltd. is a collection of science and technology development,
production and sales in one of the high-tech Company.Company engaged in LED products, including LED
scoreboard, LED oil prices display, LED clock display and LED indoor and outdoor advertising display for
Has a lot of experienced hardware engineers, software programmers, as well as doctor or master, and
other high-tech talent. Absorption and integration of domestic and foreign electronics industry advanced
technology, development and production of LED display ,automation equipment, and other areas of high-
We are devoted to the specialization of custom-built LED products to meet the special needs of each
customer, the product market covers the world.The company has excellent staff, first-class production
environment ,rigorous and efficient enterprise management system. The company has a variety of test
equipment for all products to do strict quality testing, and has passed CE and ROHS certification.
Company always revolve around to the "High quality and Customer first" business purposes.Constantly
pursuing the spirit of excellence. With first-class quality, high-quality services continue to meet the new
needs of modern technology.
